UltraSIPs
Extension Technical Drawings
Digital technical drawing package for SIP house extensions, with small and large options depending on project size and complexity.
£540.00
Inc VAT. Digital delivery for drawings. Lead time approx. 7-14 days.
UltraSIPs
Extension Technical Drawings
Digital technical drawing package for SIP house extensions, with small and large options depending on project size and complexity.
Inc. VAT. Digital delivery for drawings. Lead time approx. 7-14 days.
Digital Delivery
Digital delivery for drawings. Lead time approx. 7-14 days.
Not sure this is the right SIP product?
Send us your sizes, drawings, or intended use and we'll check the panel thickness and package before you order.
Stock
Available to order
Support
Ask us to checkWhat you get
What you get with this drawing service
A digital drawing route for customers who need the design clarified before ordering a SIP kit.
Before you order
- Digital files are supplied to your account/email once ready.
- Basket pricing is checked before checkout, so you will be prompted to refresh if a stored basket has old prices.
Included
- Digital drawing pack to the agreed scope
- 2 free amendments for drawing work started from 03/04/2026
- Email/account delivery once ready
Not included unless stated
- Physical delivery
- Structural calculations unless shown separately
- Further revisions after the included amendments
Need help before ordering?
Read the SIP panel, kit, delivery, structural allowance and installation FAQs before placing an order.
Why customers choose UltraSIPs
Extension drawing scope
Use this package to clarify the SIP extension layout, openings and package assumptions before manufacture or final quoting.
Digital delivery
Drawings are supplied digitally; no vehicle delivery is required. Lead time is typically 7-14 days once the scope is agreed.
Details
Extension technical drawing package
This drawing fee package is for customers planning a SIP house extension who need the layout, openings and SIP package details drawn up before moving further with a quote or manufacture.
Choose the package size that best matches the project. If you are unsure whether your extension is small or large, send us the drawings or sketch first and we can confirm the right option before you order.
Small extension package
- Best for straightforward smaller extensions with a simple footprint.
- Suitable where the SIP walls and roof/floor scope is clear and the number of openings is limited.
- Good for customers who need a clean technical drawing pack before finalising the SIP package.
Large extension package
- For larger extensions, more complex layouts, multiple rooms, or additional opening/detail work.
- Suitable where there are more wall runs, roof details, internal interfaces or drawing assumptions to confirm.
- Allows more drawing time before the SIP kit is priced and prepared for manufacture.
Included
- Digital technical drawing work to the agreed extension scope.
- Review of the supplied sizes, openings and SIP package assumptions.
- Two free amendments for drawing work started from 03/04/2026.
- Digital delivery by email/account once ready.
Not included unless agreed separately
- Structural calculations or engineering sign-off.
- Building Control approval, planning drawings, architect services or site surveys.
- Windows, doors, cladding, foundations, installation or delivery of physical goods.
- Further revisions after the included amendment allowance.
Please treat this as a drawing service fee. Once the layout and specification are clear, we can use the drawings to tighten the SIP package quote.
SKU: ext-technical-drawing
Lead time
Digital delivery for drawings. Lead time approx. 7-14 days.
Need drawings?
Send your sketch for a same-day review and an engineered layout. Drawing orders are supplied digitally to the agreed scope.
Send drawings
